Canton Smart Connect 5.1 User Manual

100
English
5
Use the "+" resp. the "–" key to select the desired function:
Off [OFF] means that the bass signals are played through the front speakers Front Left and Front Right.
Parallel [PAR] means that the subwoofer plays the bass signals additionally to the front speakers
Xover [XOV] means that the bass signals below the set crossover frequency Stereo Sub Xover are played through the subwoofer
6
Confirm and exit the menu item by pressing the "M" button.
Stereo Sub Xover [SSX]
With this menu item you can set the frequency at which the audio signal is split into the signal for the subwoofer and the signal for the
front speakers in the Sub Stereo Mode "Xover". This menu item is only available if the Sub Stereo Mode is set to "Xover".
To adjust the crossover frequency between subwoofer and front speakers please do the following:
1
To enter the menu, press the "M" button.
2
Use the " " or " " button to navigate into the menu Speaker Setup [SPS] and confirm with the "OK" button.
3
Use the " " or " " button to navigate into the menu Subwoofer Setup [SUB] and confirm with the "OK" button.
4
Use the " " or " " button select the menu item Stereo Sub Xover[SSX] and confirm with the "OK" button.
5
Change the setting using the "+" or "-" key between 40 Hz [40] and 100 Hz [100] and confirm with the "OK" button.
6
To exit the menu, press the Menu button "M".

Canton Smart Connect 5.1 Specifications

General

Control type	Touch
Product color	Black
Audio decoders	DTS, Dolby Digital
Built-in display	Yes
Bluetooth version	4.0
Display technology	LED
Cables included	AC
Power consumption (economy mode)	0.46 W
HDMI input ports quantity	3
HDMI output ports quantity	1

Weight and Dimensions

Depth	140 mm
Width	245 mm
Height	52 mm
Weight	1230 g
