Carel emeter1 User Manual

ENG
9
"Carel emeter" +0300044IE rel. 1.5 - 10.11.2017
emeter 1
2.6 Insulation between inputs and output
Measuring inputs Serial output Self power supply
Measuring inputs - 4kV 0kV
Serial output 4kV - 4kV
Self power supply 0kV 4kV -
Tab. 2.f
2.7 Display pages
Joystick position 1
st
line 2
nd
line Note
1a
UP
kWh total kW
1b
UP
kWh partial kW
moving joystick in
direction
2
Left
VLN (value) kW
3
Down
A (value) "A" indication
Tab. 2.g
Variable Description
1 kWh total Total energy
2 kWh partial Total partial energy
3 VLN (value) Voltage phase/neutral
4 A (value) Phase current
5kWActive power
2.8 List of available menus
Default
PASS ? Password 0
nPA New Password
Adr Instrument serial address 1
bdr Baud Rate 9.6
SYS 1P
rES Partial energy meter reset (No/Yes)
Tab. 2.h
