"Carel emeter" +0300044IE rel. 1.5 - 10.11.2017
emeter3 SE
2.4 General specifications
Operating temperature -25°C to +55°C (-13°F to 131°F) (RH from 0 to 90% non-condensing @ 40°C) in accordance with EN 62053-21 and
EN 62053-23.
Storage temperature -30°C to +70°C (from -22°F to 158°F) (RH < 90% without condensate @ 40°C) in accordance with EN 62053-21 and
EN 62053
-23.
Installation category Cat. III
Insulation (for 1 minute) 4000 VRMS between measuring inputs and output.
Dielectric strength 4000 VRMS for 1 minute.
Noise rejection (CMRR) 100 dB, from 48 to 62 Hz
EMC in accordance with EN62052-11
- Electrostatic discharges 15kV air discharge.
- Immunity to radiated
electromagnetic elds
Test with current applied: 10 V/m from 80 to 2000 MHz. T
est without current applied: 30 V/m from 80 to 2000 MHz;
- Immunity to fast transient bursts On current and voltage measuring input circuits: 4kV;
- Immunity to RF conducted disturbance from 10V/m to 150kHz to 80Mhz
- Pulse immunity On current and voltage measuring input circuits: 6kV;
- Radiofrequency emissions In accordance with CISPR 22
Standards compliance
- Safety EC60664, IEC61010-
1 EN60664, EN61010-1 EN62052-11
- Metering EN62053-21, EN62053-23, EN50470-3
- Pulse output DIN43864, IEC62053-31
- Approval CE, cULus listed (only AV)
Connections screw terminals
- Wire size 2,4 x 3,5 mm Min./Max. screw tightening torque: 0,4 Nm / 0,8 Nm
Housing
- Dimensions 72 x 72 x 65
mm
- Material Noryl PA66, ame retardant: UL 94 V-0
- Mounting Panel and DIN rail
Protection index
- Frontal IP50
- Connections IP20
Weight Around 400 g (including packaging)
Tab. 2.d
2.5 Power supply specifications
Self-powered 40 to 480VCA (45-65Hz). Between input “VL2” and “VL3”
Power consumption ≤2VA/1W
2.6 Insulation between inputs and output
Measuring inputs OPTO-MOSFET output Communication port Power supply
Measuring inputs - 4kV 4kV 0kV
OPTO-MOSFET output 4kV - - 4kV
Communication port 4kV - - 4kV
Power supply 0kV 4kV 4kV -
Tab. 2.e
NOTE: all models must be connected via external current transformers.
