36
Chapter 3: Commands and Programming
Example CFX-9800G Operation Following Data
Transfer
1. Enter the REG Mode.
2. Press [SHIFT] [SETUP] to enter the Setup Mode, and then set the follow-
ing parameters.
S-data: STO
S-graph: DRAW
3. Use [Range] to specify the graph screen range (window) in accordance
with the sampled data.
4. Use the following key sequence to clear any existing statistical data: [SHIFT]
[CLR] [F2] (Scl) [EXE].
5. Press [F6] (CAL) to recalculate the statistical data and plot the data.
6. Perform the following key operation to draw a regression graph: [Graph]
[SHIFT] [F4] (LIN) [1] [EXE].
• Try repeating the above procedure with different REG settings in the Setup
Mode until you find the setup that produces the type of regression graph
you want.
Command Reference
This section provides full details on the syntax and all of the parameters of
each of the 10 available commands.
Command 0 - All Clear
Command 0 clears all previously stored data and returns all channels to their
initial defaults.
Syntax
{0}
Description
Command 0 sends the following instructions to the data analyzer.
• Turn off all channel indicators.
• Clear all data.
• Clear all conversion equations and turn off the EQ indicator.
• If and Auto-ID probe is connected to the data analyzer, the data analyzer
also initializes the connected probe when Command 0 is received.
