Casio DT-X200-10E Service Manual

— 16 —
DT-X200/DT-X8
3-2. System Diagram
HA-K21LBAT
HA-K23XLBAT
microSD Card
DT-X200
DT-X8
Battey Pack
AC Adaptor
AD-S42120B-N5
Dual Battery Charger
HA-F32DCHG
Battey Pack
Battey Pack
Dual Battery Charger
HA-F32DCHG
Battey Pack
Battey Pack
Dual Battery Charger
HA-F32DCHG
Battey Pack
Battey Pack
Battery Terminals
microSD Card Slot
Expansion Port
Power Suplly/Data
Communication
Terminals
Bluetooth Module
(Ver2.0+EDR)
USB Terminal
(Host/Client)
IEEE802.11b/g
Module
Bluetooth Products
IEEE802.11a/b/g/n
Products
Access Point
Printer Access Point
TEL/Cellphone
HA-K36DCHG
AC Adaptor
AD-S60160B
HA-K36DCHG
USB Cradle
HA-K60IO
AC Adaptor
AD-S15050B-N5
AC Adaptor
AD-S15050B-N5
USB and Charging Unit
HA-K65US
USB Prodect
AC Adaptor
AD-S42120B-N5
Ethernet Cradle
HA-K62IO
HA-K36DCHG
USB Client
USB Client
USB Client
USB Host
LAN Port
PC
