— 74 —
DT-X200/DT-X8
7-2. PARTS LIST
1 DT-X200-10E
2 DT-X200-11E
3 DT-X200-20E
4 DT-X200-21E
5 DT-X200-41E 6 DT-X8-10C-CNV
7 DT-X8-20C-CNV
1234567
FINAL-ASSY
1 10385321 PACKING/SUP RJC505199-001V01 1111111C
2 10385354 LOCK/SUP RJC505303-001V01 1111111C
N 3 10500654 COVER/EXT RJC505223-002V01 1111111C
N 4 10500656 PLATE/G RJC505380-006V01 1111111X
N 5 10512117 COVER/BATTERY/LARGE RJC505419*003 TK 1111111C
N 6 10497489 FILTER/LASER RJC507366-001V01 00 0 C
N 6 10560722 FILTER/LASER RJC507717-001V01 1 1 1 C
6 10397136 FILTER/2D RJC505227-001V02 00 0C
N 6 10560723 FILTER/2D RJC507718-001V01 1 1 1 C
6 10409231 FILTER/FRI RJC506032-001V01 1 C
7 10394492 TAPE/BLIND RJC505639-001V02 1111111X
8 10385333 PLATE/SCREW RJC505201-001V01 2222222X
9 10363796 TAPE/CONNECTOR/G RJC503687-007V01 2222222X
N 10 10512113 UPPER-CASE-UNIT RJC505386*004 TK 11111 C
N 10 10512114 UPPER-CASE-UNIT RJC505386*005 TK 1 1 C
N 11 10512118 LOWER-CASE-UNIT RJC505411*010 TK 1 1 1 1 C
N 11 10512119 LOWER-CASE-UNIT RJC505411*011 TK 1 1 C
N 11 10512120 LOWER-CASE-UNIT RJC505411*012 TK 1 C
89 10407294 SHEET/PLATE RJC506041-001V01 2222222X
S1 10245664 SCREW RJC502686-001V01 2222222X
S2 10303505 SCREW RJC503866-001V01 2222222X
S3 10387984 SCREW RJC505567-001V01 2222222X
S4 10392851 SCREW RJC505566-003V02 6666666X
LABEL
N 12 10495347 LABEL/WINCE 0607-289009 0000000X
N 13 10239292 LABEL/REVISION RJC502719-001V01 1 1 1 X
13 10238204 LABEL/REVISION RJC502722-001V01 1 1 1 1 X
LABEL/RATING
N 14 10497500 LABEL/RATING RJC505826-030V01 1 X
N 14 10497501 LABEL/RATING RJC505826-031V01 1 X
N 14 10497502 LABEL/RATING RJC505826-032V01 1 X
N 14 10497503 LABEL/RATING RJC505826-033V01 1 X
N 14 10497504 LABEL/RATING RJC505826-034V01 1 X
N 14 10497505 LABEL/RATING RJC505826-035V01 1 X
N 14 10497507 LABEL/RATING RJC505826-036V01 1 X
N 14-1 10499835 LABEL/CAUTION RJC503493-007V04 1 X
RN Item Code No. Parts Name Specification
Q'ty
To Next Page
