Casio DT-X200-10E Service Manual

— 67 —
DT-X200/DT-X8
7. EXPLODED VIEW / PARTS LIST
Page
7-1. EXPLODED VIEW
7-1-1. FINAL-ASSY / LABELS ...................................................................................68
7-1-2. UPPER-CASE-UNIT .........................................................................................69
7-1-3. INNER-CASE-UNIT (1D LASER / 2D SCANNER MODEL) .............................70
7-1-4. INNER-CASE-UNIT (FULL RANGE IMAGER MODEL) ..................................71
7-1-5. LOWER-CASE-UNIT ........................................................................................ 72
7-1-6. BUNDLED ITEMS / TOOLS .............................................................................73
7-2. PARTS LIST ........................................................................................................74
7-3. CRADLE (HA-K60IO/K62IO)
7-3-1. EXPLODED VIEW ............................................................................................78
7-3-2. PARTS LIST ......................................................................................................79
7-4. USB AND CHARGING UNIT (HA-K65US)
7-4-1. EXPLODED VIEW ............................................................................................80
7-4-2. PARTS LIST ......................................................................................................81
Notes:
1.
The numbers in the item column correspond to the same numbers in exploded view.
2. MARKS:
Q: Quantity used per unit
R: Rank A: Essential
B: Stock recommended
C: Less recommended
X: No stock recommended
3. Refer the latest "Parts Price Code" at "PARTS FINDER" on the Casio Service WEB site
(https://www.servicecasio.com).
