— 79 —
DT-X200/DT-X8
Notes: 1. The numbers in the item column correspond to the same numbers in exploded view.
2. MARKS:
Q: Quantity used per unit
R: Rank A: Essential
B: Stock recommended
C: Less recommended
X: No stock recommended
3. Refer the latest "Parts Price Code" at "PARTS FINDER" on the Casio Service WEB site
(https://www.servicecasio.com).
7-3-2. PARTS LIST
1 HA-K60IO 2 HA-K62IO
12
1 10386767 CASE/UPPER RJC505523-001V01 1 1
C
2 10386768 HOOK/TOP RJC505524-001V01 1 1
X
3 10386769 GUIDE/PDT RJC505525-001V01 1 1
X
4 10278771 PANEL/LED RJC502220-002V01 1 1
X
5 10386770 PANEL/CN RJC505526-001V01 1
X
5 10386775 PANEL/CN RJC505547-001V01 1
X
6 58610682 COVER/DUST TM-8-DC 1
X
7 10080409 CAP/USB RJC500219-001V01 1 1
X
8 10289853 CAP/USB/CONNECTOR TK-UCAP2(1/6) 1
X
9 10386771 LABEL/RATING RJC505527-001V01 1
X
9 10386777 LABEL/RATING RJC505527-002V01 1
X
10 10303112 LABEL/S-REV RJC503972-001V01 1 1
X
11 10386772 PDT-UNIT RJC505528*001V01 1
B
N 11 10403584 PDT-UNIT RJC505528*002V01 1
B
12 10386784 PLATE/LOWER RJC505535-001V01 1 1
X
13 10386785 BEZEL/SIDE RJC505536-001V01 1
X
13 10386787 BEZEL/SIDE RJC505539-001V01 1
X
14 10386786 PCB ASSY/MAIN RJC505551*001V01 1
A
N 14 10403581 PCB ASSY/MAIN RJC504960*004V01 1
A
15 10375573 ASSY/SW RJC504999*001V01 1 1
X
16 10384669 HEAT SHEET RJC505371-001V01 1
X
17 10388067 RUBBER/FOOT RJC505563*001V01 4 4
X
18 10389685 LABEL/CA RJC505560-001V01 1 1
X
19 10386781 BUTTON/DET RJC505532-001V01 1 1
X
N 20 10403591 LIFT RJC505677-001 2 2
X
N 21 10403592 SPRING/LIFT RJC505678-001 2 2
X
22 10291747 WIRE ASSY/PDT RJC503722*001V01 1 1
X
23 10291748 WIRE ASSY/USB RJC503723*001V01 1 1
X
S1 10097195 SCREW S-BDB0-3X8NI 4 4
X
S2 10102278 SCREW S-BDB0-2X6NI 11 11
X
S3 10102311 SCREW S-PADLMA-2X6NI 4 4
X
N Code No. Parts NameItem Specification
Q'ty
R
