– 21 –
DT-X200/DT-X8
5-3. Installing the Test Program
5-3-1. How to obtain the test program
The Service Utility Software (test program) is available as follows.
Download from the following website for the Authorized Service Center.
URL: https://www.servicecasio.com
File name: Diag_dtx200-x8.zip
(To log in, a representative is requested to enter LOGIN ID and PASSWORD.)
5-3-2. Unzipping and copying the test program to microSD (on PC)
1. Unzip a “Diag_dtx200-x8.zip” fi le on your PC.
The following folders and fi les appear on your PC.
Folder File name
\DIAG BTLineTest (Shortcut)
CradleUSBTest (Shortcut)
Diag.ini
Diag_PY052EC7.exe
HowlingChk.exe
IdChk_PY052EC7.exe
IdSet_PY052EC7.exe
ModelInfo.ini
WLANCalib.exe
WLANTest (Shortcut)
zDiagDelete.exe
\DIAG\MENU PY052BCAssemblyMenu.txt, PY052BCPatternMenu.txt,
PY052BFAssemblyMenu.txt, PY052BFPatternMenu.txt,
PY052BFCAssemblyMenu.txt, PY052BFCPatternMenu.txt,
PY052CCAssemblyMenu.txt, PY052CCPatternMenu.txt,
PY052CFAssemblyMenu.txt, PY052CFPatternMenu.txt,
PY052RCAssemblyMenu.txt, PY052RCPatternMenu.txt,
PY052RFAssemblyMenu.txt, PY052RFPatternMenu.txt,
PY052RFCAssemblyMenu.txt, PY052RFCPatternMenu.txt,
PY052UCAssemblyMenu.txt, PY052UCPatternMenu.txt,
PY052UFAssemblyMenu.txt, PY052UFPatternMenu.txt,
PY052WCAssemblyMenu.txt, PY052WCPatternMenu.txt,
PY052WFAssemblyMenu.txt, PY052WFPatternMenu.txt
\DIAG\WLAN BTLineTest.exe, BTServer.exe, BTTest.dat, BTTest.ini,
FLCE.exe, FLCE (Shortcut)
wlancfg1.ini, wlancfg2.ini, wlancfg3.ini, wlancfg4.ini,
wlancfg5.ini, wlancfg6.ini, wlancfg7.ini, wlancfg8.ini
WLANTest.exe
\DIAG\WLAN(11a) 11aWLANTest.exe, FLCE.exe, FLCE (Shortcut),
wlancfg1.ini, wlancfg2.ini, wlancfg3.ini, wlancfg4.ini,
wlancfg5.ini, wlancfg6.ini, wlancfg7.ini, wlancfg8.ini
2. Copy the unzipped above folders to the root directory of the microSD card (for both test object
DT-X200/DT-X8 and opponent DT-X200/DT-X8).
To Next Page
