– 20 –
DT-X200/DT-X8
5-2. Test Equipment
The following equipment is needed for testing the hardware.
USB Cable
Test Object DT-X200/DT-X8
USB Memory
Ethernet Cradle
(HA-K62IO)
WLAN access point
(IEEE802.11b/g)
Recommendation : Cisco 1231G
microSD Card
Opponent DT-X200/DT-X8
(For testing Bluetooth)
USB and Charging Unit
(HA-K65US)
DC power supply
Output : 0 - 10 V, 3 A
DC voltage meter
Range : 0 - 10 V
DC ammeter
Range : 10 mA/ 100 mA/ 1 A
AC Adaptor for Ethernet Cradle
( AD-S42120B-N5)
AC Adaptor for
USB and Charging Unit
( AD-S15050B-N5)
Power Cord for Europe: AC-CORD-EU
Power Cord for America: AC-CORD-US
Power Cord for Taiwan: AC-CORD-TW
Power Cord for Korea: AC-CORD-KR
Power Cord for Australia: AC-CORD-AU
PC: None specified.
(Pre-installation of the Microsoft ActiveSync/
Windows Mobile Device Center is required.)*1
*1: Depends on OS to be used.
(ActiveSync: for Windows XP or earlier,
Windows Mobile Device Center:
for Windows Vista or later)
RFID tag
(85×54 mm)
To Next Page
