Part VI
Parameter Set List
This list shows the parameter sets that can be transferred using System Exclusive Message Bulk Dump.
21 SMF Parameter Set (PX-310)
System Exclusive Format
Data Format
Bulk dumping SMF data transfers the data with a 128-byte header appended as shown below. The header data starts with
an 8-byte file name, which is displayed by the Instrument after receipt.
22 About Parameter Set (PS) numbers
When using a system exclusive message to transfer a user Parameter Sets or user Parameter Set parameters, the
specified Parameter Set number do not necessarily need to start from zero when the Parameter Set numbers are
located after the preset Parameter Set. Refer to the table below for user area Parameter Set number for each
category.
Field Value
01 SYSEX F0
02 MAN 44
03 MOD 11,03
04 dev 00 to 1F, or 7F
05 act 04(HDS), 05(HDR), 07(Control)
06 cat SMF = 10
07 prm 00-7F
08 ilen/dlen See "Part IV PX-110/PX-310/PX-700 System Exclusive Message".
09 ps Indicates the SMF number being transferred.
For details, see "21 About Parameter Set (PS) numbers".
10 index See "PX-110/PX-310/PX-700 Instrument System Exclusive Messages".
11 data See "PX-110/PX-310/PX-700 Instrument System Exclusive Messages".
12 sum See "PX-110/PX-310/PX-700 Instrument System Exclusive Messages".
13 EOX F7
Header 128Bytes Name 8Bytes
Reserved 120Bytes
SMF Data
PS Category User PS Header (Decimal) Number of User PS (Decimal)
SMF 0 10
To Next Page
