Casio XJ-V100W User Manual

22
To check the power saving level
1. Press the [ ] key.
 This displays a light control dialog box. The current power saving level is indicated by leaf ( )
marks at the top of the dialog box. The more leaf marks there are, the higher the power saving
level.
 At this time you can adjust the light output level using the [] and [] keys.
2. To close the dialog box, press the [ESC] key.
Note
 The above operation cannot be performed while “Off” is selected for the “Light Control”
setting on the Setup Menu.
To turn the light sensor control on or off (XJ-F Series only)
1. Press the [MENU] key to display the Setup Menu.
2. Use the [] key to select “Option Settings 1”, and then press the [ENTER] key.
3. Use the [] key to select “Light Control” and then press the [ENTER] key.
 This displays a light control dialog box.
4. Use the [] key to select “Light Sensor” and then press the [] key to select
“On” or the [] key to select “Off”.
5. Press the [ESC] key to exit the Setup Menu.

Casio XJ-V100W Specifications

General

Matrix size	0.65 \
Native aspect ratio	16:10
Projection distance	- m
Projection technology	DLP
Contrast ratio (typical)	20000:1
Screen size compatibility	35 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-30 -30 °
Offset	33 %
Throw ratio	1.32 - 1.93:1
Zoom capability	Yes
Focal length range	18.9 - 27.2 mm
Aperture range (F-F)	2.31 - 2.73
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Maximum analog resolution	1920 x 1200 pixels
USB 2.0 ports quantity	0
Password protection type	Power on
Card reader integrated	-
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.12 W
Power consumption (typical)	135 W
Remote control type	IR
Harmonized System (HS) code	85286200

Weight and Dimensions

Width	299 mm
Height	97 mm
Weight	3500 g
