Casio XJ-V100W User Manual

3
Contents
Useful Features and Functions ...................................... 7
XJ-V10X/XJ-V100W/XJ-V110W................................................................................... 7
XJ-F10X/XJ-F100W ..................................................................................................... 8
XJ-F20XN/XJ-F200WN/XJ-F210WN (Network Models) .............................................. 9
XJ-V100W/XJ-V110W/XJ-F100W/XJ-F200WN/XJ-F210WN (WXGA Models) ............ 9
Getting Ready................................................................ 10
Setting Up the Projector.......................................................................10
Setup Precautions ..................................................................................................... 10
Connecting Projector Cables ...............................................................11
Remote Controller ................................................................................12
To load remote controller batteries .......................................................................... 13
To replace remote controller batteries...................................................................... 13
Operating the Projector................................................ 14
Selecting the Input Source (INPUT)......................................................14
To select the input source........................................................................................ 15
Resolution .................................................................................................................. 15
Output Image Operations.....................................................................16
To use manual keystone correction (KEYSTONE) .................................................... 16
To zoom an image (D-ZOOM).................................................................................. 16
To momentarily blank the image and mute the audio (BLANK)................................. 17
To freeze an image (FREEZE)................................................................................... 17
To auto adjust an image (AUTO) .............................................................................. 17
To change the aspect ratio of the projected image (ASPECT) .................................. 17
To adjust image brightness (FUNC).......................................................................... 19
To change the color mode (FUNC)........................................................................... 19
Adjusting the Volume Level (VOLUME) ................................................20
To adjust the volume level........................................................................................ 20
To mute the audio ................................................................................................... 20
Light Control.........................................................................................21
To turn light control on or off.................................................................................... 21
To adjust light output............................................................................................... 21
To check the power saving level .............................................................................. 22
To turn the light sensor control on or off (XJ-F Series only)....................................... 22

Casio XJ-V100W Specifications

General

Matrix size	0.65 \
Native aspect ratio	16:10
Projection distance	- m
Projection technology	DLP
Contrast ratio (typical)	20000:1
Screen size compatibility	35 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-30 -30 °
Offset	33 %
Throw ratio	1.32 - 1.93:1
Zoom capability	Yes
Focal length range	18.9 - 27.2 mm
Aperture range (F-F)	2.31 - 2.73
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Maximum analog resolution	1920 x 1200 pixels
USB 2.0 ports quantity	0
Password protection type	Power on
Card reader integrated	-
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.12 W
Power consumption (typical)	135 W
Remote control type	IR
Harmonized System (HS) code	85286200

Weight and Dimensions

Width	299 mm
Height	97 mm
Weight	3500 g
