Cisco 850 Series and Cisco 870 Series Access Routers Hardware Installation Guide
OL-5331-01
Chapter 1 Product Overview
Hardware Features
Integrated 802.11b/g Radio Module (Wireless Models Only)
The Cisco 850 series and Cisco 870 series wireless routers have an integrated IEEE 802.11b/g radio
module that operates as a wireless access point in infrastructure mode. The wireless routers have two
reverse-polarity threaded Neill-Concelman (RP-TNC) connectors on the back panel. The dipole swivel
antennas that were shipped with the router connect to the RP-TNC connectors to operate the 802.11b/g radio
module.
The wireless operations can be configured by using the Cisco Router and Security Device Manager
(SDM) web-based application, or by using the Cisco IOS command-line interface (CLI). See the
Cisco
Router and Security Device Manager (SDM) Quick Start Guide or the Cisco Access Router
Wireless Configuration Guide for more information.
ETHERNET LAN 0 Green On when a device connects to the Ethernet LAN 0 port. Blinks when
the Ethernet LAN 0 port receives or sends data, or when data passes
through the port.
All Cisco 850
series and
Cisco 870
series
ETHERNET LAN 1 Green On when a device connects to the Ethernet LAN 1 port. Blinks when
the Ethernet LAN 1 port receives or sends data, or when data passes
through the port.
All Cisco 850
series and
Cisco 870
series
ETHERNET LAN 2 Green On when a device connects to the Ethernet LAN 2 port. Blinks when
the Ethernet LAN 2 port receives or sends data, or when data passes
through the port.
All Cisco 850
series and
Cisco 870
series
ETHERNET LAN 3 Green On when a device connects to the Ethernet LAN 3 port. Blinks when
the Ethernet LAN 3 port receives or sends data, or when data passes
through the port.
All Cisco 850
series and
Cisco 870
series
Table 1-2 LED Indicators on the Routers (continued)
LED Color Description Router Model

Cisco 870 Series Specifications

General

Brand	Cisco
Model	870 Series
Category	Network Router
Language	English
