Appendix A Specifications
LAN Port Pinouts
For information on regulatory compliance, see the Regulatory Compliance and Safety Information for
Cisco
800 Series and SOHO Series Routers document that was shipped with your router.
Warning Ultimate disposal of this product should be handled according to all national laws and regulations.
Statement 1040
LAN Port Pinouts
Table A-3 provides pinouts for the Ethernet LAN port on the routers.
Environmental Operating Ranges
Nonoperating temperature –4 to 149°F (–20 to 65°C)
Nonoperating humidity 5 to 95% relative humidity
Nonoperating altitude 0 to 15,000 ft (4570 m)
Operating temperature 32 to 104°F (0 to 40°C)
Operating humidity 10 to 85% relative humidity
Operating altitude 0 to 10,000 ft (3000 m)
Power
AC input voltage 100 to 240 VAC
Frequency 50 to 60 Hz
Power output 80 W maximum
Output voltage 48 VDC
Table A-2 POE Module Specifications (continued)
Description Design Specification
Ta b l e A-3 Ethernet LAN Port Pinouts
Pin Function
1 RX+
2 RX–
3 TX+
4 Unused
5 Unused
6 TX–
7 Unused
8 Unused

Cisco 870 Series Specifications

General

Brand	Cisco
Model	870 Series
Category	Network Router
Language	English
