A-1
Cisco 850 Series and Cisco 870 Series Access Routers Hardware Installation Guide
OL-5331-01
APPENDIX
A
Specifications
This appendix provides system, port, and cabling specifications for Cisco 850 series and Cisco 870
series routers. It contains the following sections:
• Router Specifications, page A-1
• Power-over-Ethernet Module Specifications, page A-2
• LAN Port Pinouts, page A-3
• Console Connector Pinouts, page A-4
• ADSL Port Connector Pinouts, page A-4
• Power Output Connector Pinouts, page A-5
• Cable Specifications, page A-5
Router Specifications
Table A-1 outlines the system specifications for the routers.
Ta b l e A-1 Router Specifications
Description Design Specification
Physical Dimensions
Dimensions (H x W x D) • With antenna connectors: 2.0 x 10.25
x
9.13 in. (51 x 260 x 232 mm)
• Without antenna connectors: 2.0 x 10.25
x
8.5 in. (51 x 260 x 216 mm)
Weight (not including desktop power supply) 2.10 lb (0.95 kg)
Environmental Operating Ranges
Nonoperating temperature –4 to 149°F (–20 to 65°C)
Nonoperating humidity 5 to 95% relative humidity
Nonoperating altitude 0 to 15,000 ft (4570 m)
Operating temperature 32 to 104°F (0 to 40°C)
Operating humidity 10 to 85% relative humidity
Operating altitude 0 to 10,000 ft (3000 m)
