Cisco 850 Series and Cisco 870 Series Access Routers Hardware Installation Guide
OL-5331-01
Chapter 1 Product Overview
Hardware Features
Supported Cisco Radio Antennas (Wireless Models Only)
Table 1-3 lists the Cisco antennas that are supported on the Cisco 850 series and Cisco 870 series
wireless routers.
External Power-over-Ethernet Module (Optional)
The optional external power-over-Ethernet (PoE) module is a standalone device that connects to the
Ethernet ports on the router on one side (To ROUTER) and to powered devices (such as PCs, laptops,
and IP phones) on the other side (To LAN). The PoE module has an independent power source that can
provide inline power to devices connected to each of the four Ethernet ports, so that these devices do not
need separate power sources.
Ta b l e 1-3 Cisco Antennas Supported on the Cisco 850 Series and Cisco 870 Series Wireless Routers
Cisco Part Number Antenna Type Maximum Gain Description
23.7786.51 Omnidirectional 2.2 dBi This is the default antenna. Swivel-mount dipole
antenna operating in the 2.4- to 2.5-GHz band. This
antenna is designed for use with Cisco wireless
products utilizing an RP-TNC connector. For more
information, see the
Cisco 2.4-GHz Swivel-Mount
Dipole Antenna (23.7786.51) document.
AIR-ANT4941 Omnidirectional 2.2 dBi Swivel-mount dipole antenna operating in the 2.4-
to 2.5-GHz band. This antenna is designed for use
with Cisco wireless products utilizing an RP-TNC
connector. For more information, see the
Cisco Aironet 2.4 Ghz Articulated Dipole Antenna
(AIR-ANT4941) document.
AIR-ANT1728 Omnidirectional 5.2 dBi Ceiling-mount antenna operating in the 2.4- to
2.5-GHz band. This antenna has a clip that allows
it to be mounted to a drop-ceiling cross member.
For more information, see the
Cisco Aironet High
Gain Omnidirectional Ceiling Mount Antenna
(AIR-ANT1728) document.
Note This antenna is not supported in Japan.
AIR-ANT3549 Patch 9 dBi Wall-mount antenna operating in the 2.4- to
2.5-GHz band.
Note This antenna is not supported in the
United
States and Canada.
AIR-ANT5959 Diversity
omnidirectional
2.35 dBi Ceiling-mount antenna operating in the 2.4- to
2.5-GHz band. This antenna has a clip that allows
it to be mounted to a drop-ceiling cross member.
For more information, see the
Cisco Aironet 2 dBi
Diversity Omnidirectional Ceiling Mount Antenna
(AIR-ANT5959) document.
