Cisco 870 Series User Manual

4-19
Cisco 850 Series and Cisco 870 Series Access Routers Hardware Installation Guide
OL-5331-01
Chapter 4 Router Cabling Procedures
Connecting a G.SHDSL Line
Figure 4-15 Connecting the ADSLoISDN Port to an ADSL Line
Perform the following steps to connect the ADSL line to a cable wall jack:
Step 1 Connect the RJ-11 end of the ADSL cable to the ADSLoISDN port on the router.
Step 2 Connect the other RJ-11 end of the ADSL cable to the local ADSL connector port on the ADSL splitter
(provided by the ADSL service provider).
Step 3 Connect the unshielded Category 5 cable from the outside ADSL port on the splitter to a wall jack.
Connecting a G.SHDSL Line
This section applies to the Cisco 878 router only. To connect the router to a G.SHDSL line, perform the
steps given after
Figure 4-16.
1 One end of the ADSL cable that connects to
the router
4 RJ-11 end of the ADSL cable that connects to
the splitter
2 ADSL splitter 5 Other end of the unshielded Category 5 cable
that connects to the wall jack
3 RJ-11 end of an unshielded Category 5 cable
that connects to the splitter
A
D
S
L o
IS
D
N
IS
D
N
S
/T
L
A
N
F
E
0FE
1
F
E
2F
E
3
Cisco 876W
C
O
N
S
O
LE
A
U
X
R
E
S
E
T
+5
,+1
2 V
D
C
LE
FT
R
IG
H
T / P
R
IM
A
R
Y
117963
2
1
3
4
5
A
U
X

Cisco 870 Series Specifications

General

Brand	Cisco
Model	870 Series
Category	Network Router
Language	English
