Cisco GS7000 User Manual

Appendix A
Technical Information
156
Forward Equalizer Chart
1.2 GHz Forward Linear Equalizers
The following table shows the 1.2 GHz forward linear equalizer loss.
EQ Value
Insertion Loss at (MHz)
Total Tilt
(dB)
1218
1000
(52-1218 MHz)
1.5
1.0
1.3
1.5
3.0
1.0
1.6
3.0
4.5
1.0
1.8
4.5
6.0
1.0
2.1
6.0
7.5
1.0
2.4
7.5
9.0
1.0
2.6
9.0
10.5
1.0
2.9
10.5
12.0
1.0
3.2
12.0
13.5
1.0
3.5
13.5
15.0
1.0
3.7
15.0
16.5
1.0
4.0
16.5
18.0
1.0
4.3
18.0
19.5
1.2
4.8
19.5
21.0
1.2
5.0
21.0
22.5
1.2
5.3
22.5
24.0
1.2
5.6
24.0
