0/0 NCS1002 0.1 CTRL_BKP_UP B CURRENT 1.22
0/0 NCS1002 0.1 CTRL_FPGA_LOW CURRENT 1.22 1.22
0/0 NCS1002 0.1 CTRL_FPGA_UP CURRENT 1.22 1.22
0/RP0 NCS1K-CNTLR-K9 0.1 BIOS_Backup BS CURRENT 13.10
0/RP0 NCS1K-CNTLR-K9 0.1 BIOS_Primary S CURRENT 13.10 13.10
0/RP0 NCS1K-CNTLR-K9 0.1 Daisy_Duke_BKP BS CURRENT 0.15
0/RP0 NCS1K-CNTLR-K9 0.1 Daisy_Duke_FPGA S CURRENT 0.15 0.15
In the above output, the Status of the CDSP_PORT_19 is UPGD FAIL. For more information on the different states of
the firmware, see Verifying the Firmware Version, on page 16.
Step 2 show hw-module slice slice_number
Displays the slice and Datapath FPGA (DP FPGA) information of the NCS 1002.
The following example is for Release 6.0.1:
Example:
RP/0/RP0/CPU0:ios# show hw-module slice 2
Tue Apr 12 09:09:24.527 UTC
Slice ID: 2
Status: Provisioned
Client Bitrate: 40
Trunk Bitrate: 200
DP FPGA Version: F-203
HW Status: CURRENT
Client Port - Trunk Port CoherentDSP0/0/0/20
Traffic Split Percentage
FortyGigECtrlr0/0/0/14 100
FortyGigECtrlr0/0/0/15 100
FortyGigECtrlr0/0/0/16 100
FortyGigECtrlr0/0/0/17 100
FortyGigECtrlr0/0/0/18 100
In the above output, DP FPGA Version indicates the image of the datapath FPGA. Here, F-203 is the image version of
the 40 G image. The CURRENT value of the HW Status parameter indicates that the firmware version is the latest.
T indicates 10 G and H indicates 100 G image versions. If Need UPG appears in the output, you must upgrade the slice
to get the updated DP FPGA using the upgrade hw-module slice slice_number re-provision command.
What to do next
Upgrade the required firmware by using the upgrade hw-module location 0/0 fpd fpd_device_name command
or update all the FPDs using the upgrade hw-module location all fpd fpd_device_name command in the
Cisco IOS XR EXEC mode. After an upgrade is completed, the Status column shows RLOAD REQ if the
ISO image requires reload.
If Reload is Required
If the FPGA location is 0/RP0, use the admin hw-module location 0/RP0 reload command. This command
reboots only the CPU. Hence, the traffic is not impacted. If the FPGA location is 0/0, use the admin hw-module
location all reload command. This command reboots the chassis. Hence, the traffic is impacted. After the
reload is completed, the new FPGA runs the current version.
Troubleshooting Guide for Cisco NCS 1002, IOS XR Release 6.3.x
15
General Troubleshooting
Troubleshooting Firmware Upgrade Failure
