Troubleshooting Breakout Ports
The client port can be enabled in normal mode or breakout mode. When the client bit rate is 10G, the mode
is breakout mode. You must map a lane to a 10G port.
Before you begin
All the five client ports of the slice need to be configured with the same bit rate.
Step 1 show controllers optics R/S/I/P pm current 15-min optics lanenumber
Displays the PM data for the optics controller.
In the following example, Lane 1 is monitored within the Optics 0/1/0/0 corresponding to the 10G Ethernet controller
0/1/0/0/1.
Example:
RP/0/RP0:ios# show controllers optics 0/1/0/0 pm current 15-min optics 1
Tue Feb 10 14:59:06.945 UTC
Optics in the current interval {14:45:00 - 14:59:05 Tue Feb 15 2015]
Optics current bucket type : Valid
MIN AVG MAX Threshold(Min) TCA(enable) Threshold(Max) TCA(enable)
LBC[mA] : 735 735 735 0 NO 0 NO
OPT[dBm]:-1.23 -1.23 -1.23 2.5 NO 3.5 NO
OPR[dBm]:-1.07 -1.07 -1.07 -23.98 NO -7.5 NO
In the following example, Lane 2 is monitored within the Optics 0/1/0/0 corresponding to the 10G Ethernet controller
0/1/0/0/2.
RP/0/RP0:ios# show controllers optics 0/1/0/0 pm current 15-min optics 2
Tue Feb 10 14:59:10.936 UTC
Optics in the current interval {14:45:00 - 14:59:11 Tue Feb 15 2015]
Optics current bucket type : Valid
MIN AVG MAX Threshold(Min) TCA(enable) Threshold(Max) TCA(enable)
LBC[mA] : 770 770 770 0 NO 0 NO
OPT[dBm]:-1.25 -1.25 -1.25 2.5 NO 3.5 NO
OPR[dBm]:-1.41 -1.41 -1.41 -23.98 NO -7.5 NO
Step 2 show controllers opticsR/S/I/P
Displays details about the optics controller.
In the following example, you can view the parameters for each lane of the Optics 0/2/0/0 controller.
Example:
RP/0/RP0/CPU0:ios# show controllers optics 0/2/0/0
Tue Feb 13 15:35:34.051 UTC
optics: Driver is not sending wave channel number and grey wavelength.
Controller State: Administratively Down
Transport Admin State: Out Of Service
Laser State: Off
LED State: Off
Troubleshooting Guide for Cisco NCS 1002, IOS XR Release 6.3.x
25
General Troubleshooting
Troubleshooting Breakout Ports
