• READY—The firmware of the FPD is ready for an upgrade.
• NOT READY—The firmware of the FPD is not ready for an upgrade.
• NEED UPGD—A newer firmware version is available in the installed image. It is recommended that an upgrade
be performed.
• RLOAD REQ—The upgrade has been completed, and the ISO image requires a reload.
• UPGD DONE—The firmware upgrade is successful.
• UPGD FAIL—The firmware upgrade has failed.
• BACK IMG—The firmware is corrupted. Reinstall the firmware.
• UPGD SKIP—The upgrade has been skipped because the installed firmware version is higher than the one
available in the image.
• Running—Current version of the firmware running on the FPD.
CFP2 upgrade is not supported in 6.0.
Note
Step 2 show hw-module slice slice_number
Displays the slice and Datapath FPGA (DP-FPGA) information of the NCS 1002.
In Release 6.0.1, the following example displays the slice and DP-FPGA of the NCS 1002.
Example:
RP/0/RP0/CPU0:ios# show hw-module slice 2
Tue Apr 12 09:09:24.527 UTC
Slice ID: 2
Status: Provisioned
Client Bitrate: 40
Trunk Bitrate: 200
DP FPGA Version: F-203
HW Status: CURRENT
Client Port - Trunk Port CoherentDSP0/0/0/20
Traffic Split Percentage
FortyGigECtrlr0/0/0/14 100
FortyGigECtrlr0/0/0/15 100
FortyGigECtrlr0/0/0/16 100
FortyGigECtrlr0/0/0/17 100
FortyGigECtrlr0/0/0/18 100
In the above output, DP FPGA Version indicates the image of the datapath FPGA. Here, F-203 is the image version of
the 40 G image. The CURRENT value of the HW Status parameter indicates that the firmware version is the latest.
T indicates 10 G and H indicates 100 G image versions. If Need UPG appears in the output, you must upgrade the slice
to get the updated DP FPGA using the upgrade hw-module slice slice_number re-provision command.
The different Status are:
• Provisioned—Indicates slice is provisioned
• Provisioning in progress—Indicates slice provisioning is in progress
• Not provisioned—Indicates slice is not provisioned
Troubleshooting Guide for Cisco NCS 1002, IOS XR Release 6.3.x
17
General Troubleshooting
Verifying the Firmware Version
