Table 21: RJ-45 ToD/1-PPS Port Pinouts
DescriptionDirectionSignal NamePin
–––1
–––2
1PPS RS422 signalOutput or Input1PPS_N3
––GND4
––GND5
1PPS RS422 signalOutput or Input1PPS_P6
Time-of-Day characterOutput or InputTOD_N7
Time-of-Day characterOutput or InputTOD_P8
USB Flash or MEM Port Pinouts
The following table summarizes the USB flash or MEM port pinouts.
Table 22: USB Flash or MEM Port Pinouts
DescriptionSignal NamePin
+5 VDCVccA1
Data -D-A2
Data +D+A3
GroundGndA4
Console Port Pinouts
The following table summarizes the Console port pinouts.
Table 23: Console Port Pinouts
DescriptionDirectionSignal NamePin
Loopback 1NALoop11
Loopback 2NALoop22
Console RS232 transmitOutputTxD3
GroundNAGnd4
Hardware Installation Guide for Cisco NCS 5700 Series Fixed-Port Routers
113
System Specification
USB Flash or MEM Port Pinouts
