Port ConfigurationVariant
A total of 30 ports:
• 24x100G QSFP-DD
• 6x400G QSFP-DD
NCS-57B1-6D24H-S (Perpetual
Licensing)
NCS-57B1-6D24-SYS (Flexible
Consumption Model)
Also known as non-SE variant
For more information on its features and benefits, see the Cisco NCS-57B1 Fixed Chassis Data Sheet.
NCS-57C3-MOD
The NCS-57C3-MOD routers provide a power-efficient package with up to 2.4 Terabits of optimized forwarding
capacity.
Table 2: Cisco NCS-57C3-MOD Chassis Variants
Port ConfigurationVariant
A total of 52 ports:
• 48 ports of 25G SFP28
• 4 ports of 100G QSFP28
In addition, the chassis has 3 Modular Port Adapter (MPA) slots. See
Modular Port Adapters, on page 7 for information on MPAs.
NCS-57C3-MOD-SE-S (Perpetual
Licensing)
NCS-57C3-MODS-SYS (Flexible
Consumption Model)
Also known as SE variant
A total of 56 ports:
• 48 ports of 25G SFP28
• 8 ports of 100G QSFP28
In addition, the chassis has 3 Modular Port Adapter (MPA) slots. See
Modular Port Adapters, on page 7 for information on MPAs.
NCS-57C3-MOD-S (Perpetual
Licensing)
NCS-57C3-MOD-SYS (Flexible
Consumption Model)
Also known as non-SE variant
For more information on its features and benefits, see the Cisco NCS-57C3 Fixed Chassis Data Sheet.
Field Replaceable Units
The NCS 5700 series fixed-port routers support the following FRUs:
• Fan modules (NCS-57B1) and fan trays (NCS-57C3-MOD)
• Power Supply Units
• Modular Port Adapters (MPAs)—supported on the NCS-57C3-MOD routers
• Route Processors
All FRUs support OIR (Online Insertion and Removal).
Hardware Installation Guide for Cisco NCS 5700 Series Fixed-Port Routers
2
NCS 5700 Router Overview
Field Replaceable Units
