Install and Remove QSFP-DD Transceiver Modules
This section provides the installation, cabling, and removal instructions for the QSFP-DD transceiver modules.
The modules are hot-swappable I/O devices that connect the system’s module port electrical circuitry with
either a copper or a fiber-optic network.
The following figure shows a 400-Gigabit QSFP-DD optical transceiver. The transceiver is used primarily in
short reach applications in switches, routers, and data center equipment where it provides higher density than
SFP+ modules. The 100GE/400GE QSFP-DD optical transceiver and 100-Gigabit QSFP28 optical transceiver
are similar to the 40-Gigabit QSFP+ optical transceiver.
Figure 58: 400-Gigabit QSFP-DD Transceiver Module - Front view
Figure 59: 400-Gigabit QSFP-DD Transceiver Module - Rear view
Pull-tab latch.1
The QSFP-DD transceiver module is a static-sensitive device. Always use an ESD wrist strap or similar
individual grounding device when handling QSFP-DD transceiver modules or coming into contact with system
modules.
Caution
The QSFP-DD transceiver module has a pull-tab latch.
To install the QSFP-DD transceiver module, follow these steps:
Hardware Installation Guide for Cisco NCS 5700 Series Fixed-Port Routers
75
Connect Router to the Network
Install and Remove QSFP-DD Transceiver Modules
