CHAPTER 1
Overview
•
Overview, page 1
Overview
The Cisco Nexus 9336PQ ACI Spine Switch (N9K-C9336PQ) is a 2-rack-unit (RU) switch for the Cisco
Application-Centric Infrastructure (ACI). This switch includes the following components:
•
36 fixed 40-Gigabit Quad Small Form-factor Pluggable (QSFP+) ports
•
Console and out-of-band-management ports (one each)
• Power supplies (two—one required for operations and an optional one for redundancy)
•
Fan modules (two)
The following figure shows the hardware features seen on the power supply side of the chassis.
Figure 1: Hardware Features on the Power Supply Side of the Chassis
Fan modules (2)3Grounding Pad1
Cisco Nexus 9336PQ ACI-Mode Switch Hardware Installation Guide
1

Cisco Nexus 9336PQ Specifications

General

Brand	Cisco
Model	Nexus 9336PQ
Category	Switch
Language	English
