Cisco SG220-26P Administration Guide

Administration: Discovery
Configuring LLDP
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 86
8
STEP 4 Click Apply. The LLDP properties are defined, and the Running Configuration is
updated.
Configuring LLDP Port Settings
Use the Port Settings page to activate LLDP per port and enter the TLVs that are
sent in the LLDP PDU.
To define the LLDP port settings:
STEP 1 Click Administration > Discovery LLDP > Port Settings.
STEP 2 Select a port and click Edit.
STEP 3 Enter the following information:
• Interface—Select the port to be defined.
• Administrative Status—Select the LLDP publishing option for the port. The
available options are:
- Tx Only—Publishes only but does not discover.
- Rx Only—Discovers but does not publish.
- Tx & Rx—Publishes and discovers.
- Disable—Disables LLDP on the port.
• Available Optional TLVs—Select the information to be published by the
switch by moving the TLV to the Selected Optional TLVs list. The available
TLVs contain the following information:
- Port Description—Information about the port, including manufacturer,
product name, and hardware and software versions.
- System Name—System’s assigned name (in alphanumeric format). The
value equals the sysName object.
- System Description—Description of the network entity (in alphanumeric
format). This includes the system's name and versions of the hardware,
operating system, and networking software supported by the switch.
The value equals the sysDescr object.
