Cisco SG500X-24P Administration Guide

Smartport
Auto Smartport
Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3 182
11
NOTE If only the IP Phone and Host bits are set, then the Smartport type is
ip_phone_desktop.
Multiple Devices Attached to the Port
The device derives the Smartport type of a connected device via the capabilities
the device advertises in its CDP and/or LLDP packets.
If multiple devices are connected to the device through one interface, Auto
Smartport considers each capability advertisement it receives through that
interface in order to assign the correct Smartport type. The assignment is based
on the following algorithm:
LLDP Capabilities Mapping to Smartport Type
Capability Name LLDP Bit Smartport Type
Other 1 Ignore
Repeater IETF RFC 2108 2 Ignore
MAC Bridge IEEE Std. 802.1D 3 Switch
WLAN Access Point IEEE Std. 802.11
MIB
4 Wireless Access
Point
Router IETF RFC 1812 5 Router
Telephone IETF RFC 4293 6 ip_phone
DOCSIS cable device IETF RFC 4639
and IETF RFC 4546
7Ignore
Station Only IETF RFC 4293 8 Host
C-VLAN Component of a VLAN Bridge
IEEE Std. 802.1Q
9Switch
S-VLAN Component of a VLAN Bridge
IEEE Std. 802.1Q
10 Switch
Two-port MAC Relay (TPMR) IEEE Std.
802.1Q
11 Ignore
Reserved 12-16 Ignore
