Cisco SG500X-24P Administration Guide

IP Configuration: RIPv2
Configuring RIP
351 Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3
18
STEP 2 To clear specific interface counters, select them and click Clear Interface Counter.
To clear them all, click Clear All Interface Counters.
Displaying the RIPv2 Peers Database
To view the RIP Peers (neighbors) database:
STEP 1 Click IP Configuration > RIPv2 > RIPv2 Peer Router Database.
The following fields are displayed for the peer router database:
• Router IP Address—IP interface defined on the Layer 2 interface.
• Bad Packets Received—Specifies the number of bad packets identified by
RIP on the IP interface.
• Bad Routes Received—Specifies the number of bad routes received and
identified by RIP on the IP interface. Bad routes mean that the route
parameters are incorrect. For example, the IP destination is a Broadcast, or
the metric is 0 or greater than 16
• Last Updated—Indicates the last time RIP received RIP routes from the
remote IP address.
STEP 2 To clear all counters, click Clear All Interface Counters.
Access Lists
See Filtering Routing Updates for a description of access lists.
To create access lists, do the following:
1. Create an access list with a single IP address, using the Access List Settings
page.
2. Add additional IP addresses if required, using the Source IPv4 Address List
page.

Cisco SG500X-24P Specifications

General

Brand	Cisco
Model	SG500X-24P
Category	Switch
Language	English
