Cisco UCS C240 M4 Service Manual

C-4
Cisco UCS C240 M4 Server Installation and Service Guide
OL-32474-01
Appendix C RAID Controller Considerations
Support Matrix For Cisco UCS C240 M4 Server RAID Controllers
Support Matrix For Cisco UCS C240 M4 Server RAID Controllers
Table C-2 lists the support for the available controllers by server version.
Cisco UCS SAS 9300-8e HBA Considerations
This section contains the following topics:
• Optical Cables Not Supported for 9300-8e HBA, page C-4
• Mixing Rules, page C-4
• Cisco UCS 9300-8e Bad Drive and Predictive Failure Behavior, page C-4
• Setting the Preferred Boot Device for Cisco UCS 9300-8e, page C-5
Optical Cables Not Supported for 9300-8e HBA
The 9300-8e HBA does not support optical cables for connection to external storage (copper only).
Mixing Rules
Mixing the Cisco UCS 9300-8e HBA in the same server as the Cisco UCS 12G SAS Modular HBA
requires the following firmware levels:
• Cisco IMC/BIOS 2.0(8) or later
• Cisco UCS Manager 2.2(6) or later (for integrated servers only)
Cisco UCS 9300-8e Bad Drive and Predictive Failure Behavior
The bad drive and predictive failure behavior for the Cisco UCS SAS 9300-e HBA cards is different than
that for LSI MegaRAID cards. The list below compares behavior for these HBA cards and LSI
MegaRAID cards.
• Bad/invalid/0MB drive handling:
– MegaRAID: The bad drive is marked BAD in the GUI/CLI interfaces and the fault LED on the
drive is solid amber.
Table C-2 Support Matrix For C240 M4 RAID Controllers
C240 M4
Version
Boot SSD
(Internal)
Supported?
Embedded
Software
RAID
Control
Boot SSD
(Internal)?
AHCI
Mode
Control
Boot SSD
(Internal)?
Hardware
Controller
Card
Control
Boot SSD
(Internal)?
Embedded
Software
RAID
Control
Front-Facing
drives?
AHCI mode
Control
Front-Facing
drives?
Cisco 12G
Modular
RAID
Controller
Card Control
Front-Facing
Drives?
SAS 9300-8i
HBA Controller
Card Control
Front-Facing
Drives?
SFF 8 HDD No N/A N/A N/A Yes No Yes N/A
LFF 12 HDD Yes Yes Yes No No No Yes Yes
SFF 16 HDD No N/A N/A N/A No No Yes N/A
SFF 24 HDD Yes Yes Yes No No No Yes Yes

Cisco UCS C240 M4 Specifications

General

Tcase	78.9 °C
Bus type	QPI
Stepping	M1
Scalability	2S
Processor code	SR1YA
Processor cache	25 MB
Processor cores	10
Processor model	E5-2650V3
System bus rate	9.6 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor threads	20
Processor codename	Haswell
Motherboard chipset	Intel C610
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	3 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Embedded options available	No
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	105 W
Compatible processor series	Intel® Xeon®
Supported processor sockets	LGA 2011-v3 (Socket R)
Number of processors installed	2
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	68 GB/s
Maximum internal memory supported by processor	768 GB
HDD size	- \
RAID levels	0, 1, 5, 6, 10, 50, 60
Total storage capacity	- GB
Maximum storage capacity	- TB
Number of HDDs installed	-
Memory slots	24
Internal memory	16 GB
Memory clock speed	2133 MHz
Maximum internal memory	384 GB
Maximum graphics card memory	8 MB
Graphics card	G200e
Graphics card family	Matrox
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
LAN controller	Intel® I350
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Serial ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
Compatible operating systems	Microsoft Windows Server 2012 R2 Microsoft Windows Server 2012 Microsoft Windows Server 2008 R2 Red Hat Enterprise Linux Novell SUSE Linux Enterprise Server Oracle Linux Oracle Solaris Ubuntu Server CentOS
Chassis type	Rack (2U)
Power supply input frequency	50 - 60 Hz
Processor ARK ID	81705
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Trusted Platform Module (TPM) version	1.2
PCI Express slots version	3.0

Weight and Dimensions

Depth	738 mm
Width	448 mm
Height	87 mm
