Cisco UCS C240 M4 Service Manual

D-23
Cisco UCS C240 M4 Server Installation and Service Guide
OL-32474-01
Appendix D GPU Card Installation
Installing NVIDIA GRID License Server Software
For full installation instructions and troubleshooting, refer to the NVIDIA GRID License Server User
Guide. Also refer to the NVIDIA GRID License Server Release Notes for the latest information about
your release.
http://www.nvidia.com
Platform Requirements for NVIDIA GRID License Server
• The hosting platform can be a physical or a virtual machine. NVIDIA recommends using a host that
is dedicated only to running the License Server.
• The hosting platform must run a supported Windows OS.
• The hosting platform must have a constant IP address.
• The hosting platform must have at least one constant Ethernet MAC address.
• The hosting platform’s date and time must be set accurately.
Installing on Windows
The License Server requires a Java runtime environment and an Apache Tomcat installation. Apache
Tomcat is installed when you use the NVIDIA installation wizard for Windows.
Step 1 Download and install the latest Java 32-bit runtime environment from
https://www.oracle.com/downloads/index.html.
Note Install the 32-bit Java Runtime Environment, regardless of whether your platform is Windows
32-bit or 64-bit.
Step 2 Create a server interface:
a. On the NVIDIA Software Licensing Center dialog, click Grid Licensing > Create License Server.
b. On the Create Server dialog, fill in your desired server details.
c. Save the .bin file that is generated onto your license server for installation.
Step 3 Unzip the NVIDIA License Server installer Zip file that you downloaded previously and run setup.exe.
Step 4 Accept the EULA for the NVIDIA License Server software and the Apache Tomcat software. Tomcat is
installed automatically during the License Server installation.
Step 5 Use the installer wizard to step through the installation.
Note On the Choose Firewall Options dialog, select the ports to be opened in the firewall. NVIDIA
recommends that you use the default setting, which opens port 7070 but leaves port 8080 closed.
Step 6 Verify the installation. Open a web browser on the License Server host and connect to the URL
http://localhost:8080/licserver. If the installation was successful, you see the NVIDIA License Client
Manager interface.

Cisco UCS C240 M4 Specifications

General

Tcase	78.9 °C
Bus type	QPI
Stepping	M1
Scalability	2S
Processor code	SR1YA
Processor cache	25 MB
Processor cores	10
Processor model	E5-2650V3
System bus rate	9.6 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor threads	20
Processor codename	Haswell
Motherboard chipset	Intel C610
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	3 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Embedded options available	No
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	105 W
Compatible processor series	Intel® Xeon®
Supported processor sockets	LGA 2011-v3 (Socket R)
Number of processors installed	2
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	68 GB/s
Maximum internal memory supported by processor	768 GB
HDD size	- \
RAID levels	0, 1, 5, 6, 10, 50, 60
Total storage capacity	- GB
Maximum storage capacity	- TB
Number of HDDs installed	-
Memory slots	24
Internal memory	16 GB
Memory clock speed	2133 MHz
Maximum internal memory	384 GB
Maximum graphics card memory	8 MB
Graphics card	G200e
Graphics card family	Matrox
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
LAN controller	Intel® I350
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Serial ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
Compatible operating systems	Microsoft Windows Server 2012 R2 Microsoft Windows Server 2012 Microsoft Windows Server 2008 R2 Red Hat Enterprise Linux Novell SUSE Linux Enterprise Server Oracle Linux Oracle Solaris Ubuntu Server CentOS
Chassis type	Rack (2U)
Power supply input frequency	50 - 60 Hz
Processor ARK ID	81705
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Trusted Platform Module (TPM) version	1.2
PCI Express slots version	3.0

Weight and Dimensions

Depth	738 mm
Width	448 mm
Height	87 mm
