D-Link DAP-1620 User Manual

DAP-1620 AC1300 MU-MIMO Wi-Fi Range Extender
User Manual
Overview
Specifications
*
Hardware
Processor
· MT7621AT (880MHz, dual core)
RAM
· 128MB, DDR3 SDRAM
Flash
· 16MB, SPI
Interfaces
· 10/100/1000BASE-T LAN port
LEDs
· POWER/WPS
· Wi-Fi Signal Strength
Buttons
· WPS button to set up wireless connection
· RESET button to restore factory default settings
Antenna
· Two external non-detachable antennas (1dBi gain for 2.4GHz and 2dBi gain for
5GHz)
MIMO
· 2 x 2, MU-MIMO
Power connector
· CEE 7/16 plug for AC power supply
Software
Network functions
· DHCP server
· Advanced configuration of built-in DHCP server
· Stateful/Stateless mode for IPv6 address assignment
· Automatic obtainment of LAN IP address
· DNS relay
· Autonegotiation of speed, duplex mode, and flow control / Manual speed and
duplex mode setup for Ethernet port
Firewall functions
· MAC filter
Management and monitoring
· Access to settings through SSH/TELNET/WEB (HTTP/HTTPS)
· Multilingual web-based interface for configuration and management
· Firmware update via web-based interface
· Automatic notification on new firmware version
· Saving/restoring configuration to/from file
· Support of logging to remote host
· Automatic synchronization of system time with NTP server and manual
time/date setup
· Ping utility
· Traceroute utility
· Schedules for MAC filters rules, automatic reboot, and enabling/disabling
wireless network
* The device features are subject to change without notice. For the latest versions of the firmware and relevant
documentation, visit www.dlink.ru.
Page 6 of 125

D-Link DAP-1620 Specifications

General

Type	Network repeater
WPS push button	Yes
Maximum transfer distance	- m
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	WPA, WPA2, WPS
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ac
Wi-Fi data rate (max)	1200 Mbit/s
Certification	FCC, IC, CE, C-Tick, CB, UL, Wi-Fi Certified
Product color	White
Ethernet LAN (RJ-45) ports	1
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Antennas quantity	2
Package depth	161 mm
Package width	104 mm
Package height	94 mm
Package weight	300 g
Pallet width	1100 mm
Pallet height (air)	1479 mm
Pallet height (sea)	2055 mm
Pallet gross weight (air)	267630 g
Pallet gross weight (sea)	371900 g
Quantity per pallet (air)	700 pc(s)
Quantity per pallet (sea)	1000 pc(s)
Shipping (inner) case width	229 mm
Shipping (inner) case height	192 mm
Shipping (inner) case length	497 mm
Shipping (inner) case weight	3459 g
Shipping (inner) case net weight	3000 g
Number of cartons per pallet (air)	70 pc(s)
Number of cartons per pallet (sea)	100 pc(s)
Quantity per shipping (inner) case	10 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	59 mm
Width	120 mm
Height	42 mm
Weight	139 g
