DES-3028 DES-3028P DES-3052 DES-3052P Layer 2 Fast Ethernet Managed Switch
The following fields can be viewed:
Parameter Description
Port
The identification number assigned to the Port by the System in which the Port
resides.
Frames Rx
The number of valid EAPOL frames that have been received by this Authenticator.
Frames Tx
The number of EAPOL frames that have been transmitted by this Authenticator.
Rx Start
The number of EAPOL Start frames that have been received by this Authenticator.
TxReqId
The number of EAP Req/Id frames that have been transmitted by this Authenticator.
RxLogOff
The number of EAPOL Logoff frames that have been received by this Authenticator.
Tx Req
The number of EAP Request frames (other than Rq/Id frames) that have been
transmitted by this Authenticator.
Rx RespId
The number of EAP Resp/Id frames that have been received by this Authenticator.
Rx Resp
The number of valid EAP Response frames (other than Resp/Id frames) that have
been received by this Authenticator.
Rx Invalid
The number of EAPOL frames that have been received by this Authenticator in which
the frame type is not recognized.
Rx Error
The number of EAPOL frames that have been received by this Authenticator in which
the Packet Body Length field is invalid.
Last Version
The protocol version number carried in the most recently received EAPOL frame.
Last Source
The source MAC address carried in the most recently received EAPOL frame.
Auth State
This table displays the Authenticator State for each port. To view the Authenticator State, click Monitoring > Port Access
Control > Auth State.
200
