DES-3028 DES-3028P DES-3052 DES-3052P Layer 2 Fast Ethernet Managed Switch
Web Pages
When you connect to the management mode of the Switch with a web browser, a login window is displayed. Enter a user name
and password to access the Switch's management mode.
Below is a list and description of the main folders available in the web interface:
Administration – Contains windows concerning configuring the basic functions of the Switch, including Device Information, IP
Address, Port Configuration, DHCP/BOOTP Relay, User Accounts, Port Mirroring, System Log Settings, Log Settings, SNTP
Settings, MAC Notification Settings, TFTP Services, Multiple Image Services, Ping Test, Safeguard Engine, SNMP Manager,
PoE System, Single IP Settings, Forwarding & Filtering, and SMTP Service.
Layer 2 Features – Contains windows concerning Layer 2 features of the Switch, including VLAN, Trunking, IGMP Snooping,
and Spanning Tree.
CoS – Contains windows concerning Port Bandwidth, 802.1P Default Priority, 802.1P User Priority, CoS Scheduling Mechanism,
CoS Output Scheduling, Priority Settings, TOS Priority Settings, Port Mapping Priority Settings, and MAC Priority.
ACL – Contains the window for the Time Range, Access Profile Table, and CPU Interface Filtering.
Security – Contains windows for Traffic Control, Port Security, Port Lock Entries, SSL, SSH, 802.1x, Trusted Host, Access
Authentication Control, and Traffic Segmentation.
Monitoring – Contains windows for CPU Utilization, Port Utilization, Packets, Packet Errors, Packet Size, MAC Address, Switch
Log, IGMP Snooping Group, Browse Router Port, Static ARP Settings, Session Table, and Port Access Control.
Switch Maintenance – Contains information regarding Reset, Reboot System, Save Changes, and Logout.
NOTE: Be sure to configure the user name and password in the User
Accounts window before connecting the Switch to the greater network.
20
