DES-3028 DES-3028P DES-3052 DES-3052P Layer 2 Fast Ethernet Managed Switch
SMTP Server Settings
The following window is used to configure the fields to set up the SMTP server for the switch, along with setting e-mail
addresses to which switch log files can be sent when a problem arises on the Switch. To open the following window, open the
Administration folder, then the SMTP Service folder and then click the SMTP Server Settings link.
Figure 6- 65. SMTP Service Settings and Mail Receiver Address Table window
The following parameters can be set:
Parameter Description
SMTP State
Use the pull-down menu to enable or disable the SMTP service on this device.
SMTP Server Address
Enter the IP address of the SMTP server on a remote device. This will be the device
that sends out the mail for you.
SMTP Server Port
Enter the virtual port number that the Switch will connect with on the SMTP server.
The common port number for SMTP is 25, yet a value between 1 and 65535 can be
chosen.
Self Mail Address
Enter the e-mail address from which mail messages will be sent. This address will
be the “from” address on the e-mail message sent to a recipient. Only one self mail
address can be configured for this Switch. This string can be no more that 64
alphanumeric characters.
Mail Receiver Address
Enter a list of e-mail addresses so recipients can receive e-mail messages
regarding Switch functions. Up to 8 e-mail addresses can be added per Switch. Do
delete these addresses from the Switch, click it’s corresponding
under the Delete
heading in the Mail Receiver Address Table.
Click Apply to implement changes made.
SMTP Service
The following window is used to send test messages to all mail recipients configured on the Switch, thus testing the configurations
set and the reliability of the SMTP server. To access the following window, open the Administration folder, then the SMTP
Service folder and click the SMTP Service link.
74
