D-Link DIR-300 User Manual

DIR-300 Wireless N 150 Home Router
User Manual
Configuring via Web-based Interface
System Log
On the System / System log page, you can set the system log options and configure sending the
system log to a remote host.
Figure 121. The System / System log page. The Configuration tab.
To enable logging of the system events, select the Logging checkbox on the Configuration tab.
Then specify the needed parameters.
Control Description
Logging type
Select a type of logging from the drop-down list.
• Local: the system log is stored in the router's memory (and
displayed on the Log tab). When this value is selected, the
Server and Port fields are not displayed.
• Remote: the system log is sent to the remote host specified in
the Server field.
• Local and remote: the system log is stored in the router's
memory (and displayed on the Log tab) and sent to the
remote host specified in the Server field.
Logging level Select a type of messages and alerts/notifications to be logged.
Server
The IP or URL address of the host from the local or global network,
to which the system log will be sent.
Page 159 of 170

D-Link DIR-300 Specifications

General

Frequency Band	2.4 GHz
LAN Ports	4 x 10/100Mbps
WAN Ports	1 x 10/100Mbps
Security	WEP, WPA, WPA2
Wireless Speed	54 Mbps
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 65 °C
Humidity	10% to 90% non-condensing
Wireless Standard	802.11b/g
Antenna	1 x External
Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.11b, IEEE 802.11g
