D-Link DIR-300 User Manual

DIR-300 Wireless N 150 Home Router
User Manual
Configuring via Web-based Interface
Creating PPTP + Static IP or L2TP + Static IP WAN Connection
To create a connection of the PPTP + Static IP or L2TP + Static IP type, click the Add button on the
Net / WAN page. On the opened page, select the relevant value from the Connection Type drop-
down list and specify the needed values.
Figure 76. The page for creating a new connection. The General settings and Ethernet sections.
Parameter Description
General settings
Port
A physical or virtual interface to which the new connection will be
assigned.
Name A name for connection for easier identification.
Enable Select the checkbox to enable the connection.
Direction The direction of this connection.
Ethernet
MTU The maximum size of units transmitted by the interface.
Page 96 of 170

D-Link DIR-300 Specifications

General

Frequency Band	2.4 GHz
LAN Ports	4 x 10/100Mbps
WAN Ports	1 x 10/100Mbps
Security	WEP, WPA, WPA2
Wireless Speed	54 Mbps
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 65 °C
Humidity	10% to 90% non-condensing
Wireless Standard	802.11b/g
Antenna	1 x External
Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.11b, IEEE 802.11g
