D-Link DWR-118 User Manual

11D-Link DWR-118 User Manual
Section 4 - Conguration
Static IP
Enter the IP address provided by your ISP.
Enter the subnet mask provided by your ISP.
Enter the gateway address provided by your ISP.
Enter the primary DNS server provided by your ISP here.
Enter the secondary DNS server provided by your ISP here.
Maximum Transmission Unit - you may need to change the MTU
for optimal performance with your ISP. The default value is 0.
Enter the MAC address, or click Clone to clone your client’s MAC
address to the WAN port.
IP Address:
Subnet Mask:
Default
Gateway:
Primary DNS
Server:
Secondary DNS
Server:
MTU:
MAC Address:

D-Link DWR-118 Specifications

General

VPN support	L2TP/PPTP/IPSEC
Ethernet LAN	Yes
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	433 Mbit/s
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	4
USB version	2.0
Rack mounting	No
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
Product color	Black
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPS
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %
Certification	RoHS, CE
Antenna gain level (max)	5 dBi
Package depth	274 mm
Package width	208 mm
Package height	66 mm
Package weight	706 g
Pallet width	1100 mm
Pallet length	1200 mm
Pallet height (air)	1975 mm
Pallet gross weight (air)	418480 g
Quantity per pallet (air)	480 pc(s)
Shipping (inner) case width	290 mm
Shipping (inner) case height	230 mm
Shipping (inner) case length	360 mm
Shipping (inner) case weight	4130 g
Shipping (inner) case net weight	3530 g
Number of cartons per pallet (air)	96 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	113.5 mm
Width	148.5 mm
Height	25 mm
Weight	194.3 g
