D-Link DWR-118 User Manual

51D-Link DWR-118 User Manual
Section 5 - Connecting to a Wireless Network
Windows® 7
It is recommended that you enable wireless security (WPA/WPA2) on your wireless router or access point before conguring
your wireless adapter. If you are joining an existing network, you will need to know the security key or passphrase being used.
1. Click on the wireless icon in your system tray (lower-right corner).
2. The utility will display any available wireless networks in your area.
Wireless Icon
WPA/WPA2

D-Link DWR-118 Specifications

General

VPN support	L2TP/PPTP/IPSEC
Ethernet LAN	Yes
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	433 Mbit/s
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	4
USB version	2.0
Rack mounting	No
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
Product color	Black
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPS
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %
Certification	RoHS, CE
Antenna gain level (max)	5 dBi
Package depth	274 mm
Package width	208 mm
Package height	66 mm
Package weight	706 g
Pallet width	1100 mm
Pallet length	1200 mm
Pallet height (air)	1975 mm
Pallet gross weight (air)	418480 g
Quantity per pallet (air)	480 pc(s)
Shipping (inner) case width	290 mm
Shipping (inner) case height	230 mm
Shipping (inner) case length	360 mm
Shipping (inner) case weight	4130 g
Shipping (inner) case net weight	3530 g
Number of cartons per pallet (air)	96 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	113.5 mm
Width	148.5 mm
Height	25 mm
Weight	194.3 g
