D-Link DWR-118 User Manual

33D-Link DWR-118 User Manual
Section 4 - Conguration
To speed up conguration, you can select a service from the drop-
down menu, an ID, and click Copy to, to copy the service rules to
the specied ID.
Enter the ports used by the service.
Enter the IP address of the computer on your local network that
you want to allow the incoming service. In the next box, enter the
port number that you would like to open.
Select this box to enable the rule.
Specify the schedule rule number or click Add New Rule... to add
a new schedule rule.
Well-known
Services:
Service Ports:
Server IP: Port:
Enable:
Schedule Rule #:
Virtual Server
The device can be congured as a virtual server so that users can access services such as web or FTP via the public (WAN) IP address of the router.

D-Link DWR-118 Specifications

General

VPN support	L2TP/PPTP/IPSEC
Ethernet LAN	Yes
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	433 Mbit/s
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	4
USB version	2.0
Rack mounting	No
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
Product color	Black
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPS
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %
Certification	RoHS, CE
Antenna gain level (max)	5 dBi
Package depth	274 mm
Package width	208 mm
Package height	66 mm
Package weight	706 g
Pallet width	1100 mm
Pallet length	1200 mm
Pallet height (air)	1975 mm
Pallet gross weight (air)	418480 g
Quantity per pallet (air)	480 pc(s)
Shipping (inner) case width	290 mm
Shipping (inner) case height	230 mm
Shipping (inner) case length	360 mm
Shipping (inner) case weight	4130 g
Shipping (inner) case net weight	3530 g
Number of cartons per pallet (air)	96 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	113.5 mm
Width	148.5 mm
Height	25 mm
Weight	194.3 g
