D-Link DXS-1210 Series User Manual
104
ACL > ACL Interface Access Group
The ACL Interface Access Group page allows you to view and configure the interface access group settings.
Figure 4.165 – ACL > ACL Interface Access Group
From Port / To Port: Select the range of ports to be configured.
Direction: Select the direction.
Action: Select the action to be Add or Delete.
ACL Type: Select the ACL profile type to find. Options to choose from are All, IP ACL, IPv6 ACL, MAC
ACL, and Expert ACL.
ACL Name: Enter ACL name. The name can be up to 32 characters long.
Click the Apply button to save your settings.
After clicking the Please Select button, the following page will appear.
Figure 4.166 – ACL > ACL Interface Access Group - Select
