If your cable system only requires
you to use a converter box for
some channels
(i.e., pay-TV channels), follow these
steps: Find the primary incoming RF
cable. Plug this cable into a splitter
(available at your local electronics
store.) Connect one RF cable
between one OUT terminal on the
■ You should install a distributor additionally.
How to watch general broadcasting with recording CATV
1
1 Set Channel Select switch of Converter Box to CH 3 or 4 as same as video exclusive channel. Press [SET]
button in [VCR] operation to set video exclusive channel in ÒCHANNEL SETÓ screen.
2
2 Press channel button of Converter Box to select channel to be recorded. In this case, if you want to watch
CATV to be recorded, press [TV/INPUT] button of TV to select ÒOut (VCR)Ó.
3
3 Press [REC] button in DVD-Video.
4
4
To watch general broadcasting, press channel button in TV to select the desired channel.
splitter and the IN terminal on the converter box.
Connect another RF cable between the other OUT terminal on the splitter and the A-IN terminal on an A/B
switch (available at your local electronics store.) Connect a third RF cable between the OUT terminal on the
converter box and the B-IN terminal on the A/B switch.
Connect a RF cable between the OUT terminal on the A/B switch and the ANT. IN on your DVD-VIDEO.
When the A/B switch is in the B position, use the converter box to change channels ; when the A/B switch is in
the A position, use the DVD-VIDEO to change channels.
¥ For some types of TV, you should press [TV/INPUT] button in TV remote control and convert from Out 1( VCR 1) or
Out 2(VCR 2) mode to Broadcasting Channel mode to change TV channel.
¥ Change channel selection of CATV receiver in recording, contents of recording is changed.
<Rear Panel of DVD-VIDEO><Converter Box> <Rear Panel of TV>
RF Cable
AUDIO/VIDEO Cable
RF Cable
RF Cable
<A/B Switch>
<Splitter (Not supported)>
<Cable Antenna>
RF Cable
A83/84/53/54D1N-QS(˜ ”‚ VE2.0) 03.8.13 11:20 PM ˘`12
