4.3 Preview
After device booted up, the system is in multiple-channel display mode. See Figure 4-57.Please note the
displayed window amount may vary. The following figure is for reference only. Please refer to chapter 1.3
Specifications for the window-amount your product supported.
Figure 4-57
4.3.1 Preview
If you want to change system date and time, you can refer to general settings (Main
Menu->Setting->System->General). If you want to modify the channel name, please refer to the
display settings (Main Menu->Camera->CAM name)
Please refer to the following sheet for detailed information.
When current channel is recording, system displays this icon.
When motion detection alarm occurs, system displays this icon.
When video loss alarm occurs, system displays this icon.
When current channel is in monitor lock status, system displays this
icon.
Tips
Preview drag: If you want to change position of channel 1 and channel 2 when you are
previewing, you can left click mouse in the channel 1 and then drag to channel 2, release mouse
you can switch channel 1 and channel 2 positions.
Use mouse middle button to control window split: You can use mouse middle button to switch
window split amount.
4.3.2 Navigation bar
On the preview interface, left click mouse, you can view the navigation bar. See Figure 4-58 or Figure
4-59.
