Note
Destination IP and port refers to NVR IP address and port. System can auto get and display.
Step 3 Click OK to complete setup.
 Connection mode is RS232 or RS485.
Step 1 Click Setup.
Enter Setup interface. See Figure 4-161.
Figure 4-161
Step 2 Set address, baud rate, data bit, stop bit and parity.
Note
Make sure the parameters here are the same with the POS setup.
Step 3 Click OK to complete setup.
4.8 Network
4.8.1 Network Settings
4.8.1.1 TCP/IP
The single network adapter interface is shown as in Figure 4-162 and the dual network adapters interface
is shown as in Figure 4-163.
 Network Mode : Includes multiple access, fault tolerance, and load balancing
 Multiple-address mode: eth0 and eth1 operate separately. You can use the services such as
HTTP, RTP service via etho0 or the eth1. Usually you need to set one default card (default setup
is etho) to request the auto network service form the device-end such as DHCP, email, FTP and
etc. In multiple-address mode, system network status is shown as offline once one card is
offline.
