Dahua L Series User Manual

83
Icon
Name
Function
USB2.0 port
USB2.0 port. Connect to mouse, USB storage device,
and etc.
HDMI
High Definition
Media Interface
High definition audio and video signal output port. It
transmits uncompressed high definition video and
multiple-channel data to the HDMI port of the display
device. HDMI version is 1.4.
VGA
VGA video output
port
VGA video output port. Output analog video signal. It
can connect to the monitor to view analog video.
GND
Ground end
Wireless AP
Support wireless hotspot function. Use WIFI to
connect to the network camera when there is a
hotspot.
2.2.6 NVR22-S2/22-P-S2/22-8P-S2/2A16/22-4KS2/22-P-4KS2/22-8P-4KS2 Series
The NVR22-S2/2A16/22-4KS2 series rear panel is shown as below. See Figure 2-27.
Figure 2-27
The NVR22-P-S2/22-P-4KS2 series rear panel is shown as below. See Figure 2-28.
Figure 2-28
The NVR22-8P-S2/22-8P-4KS2 series rear panel is shown as below. See Figure 2-29.
Figure 2-29
Please refer to the following sheet for detailed information.
