Field Settings SiUS122226E
250 Part 7 Trial Operation and Field Settings
5. Field Settings
5.1 Wall Mounted/Floor Standing Type
5.1.1 Model Type Settings
ARC452A21
The remote controller is common to the heat pump model and cooling only model.
Make sure the DIP switch is set to the left side. The heating operation will not be available when
the DIP switch is set to the right side.
ARC466A21, ARC466A36
The remote controller is common to the heat pump model and cooling only model.
Replace the remote controller if you cut a jumper on the left side.
The heating operation will not be available when the jumper on the left side is cut.
(R18201)
DIP switch
Heat pump model Cooling only model
DIP switch
Never cut this jumper.
(R23955)
To Next Page
