Normal overload 110% for 1 minute
Frequency converter
Typical
Shaft Output [kW]
P30K
37
P37K
45
P45K
55
P55K
75
P75K
90
Typical
Shaft Output [HP] at 575 V 40 50 60 75 100
IP21/NEMA 1 C2 C2 C2 C2 C2
IP55/NEMA 12 C2 C2 C2 C2 C2
Output current
Continuous (3 x 525-550 V) [A] 43 54 65 87 105
Intermittent (3 x 525-550 V) [A] 47.3 59.4 71.5 95.7 115.5
Continuous (3 x 551-690 V) [A] 41 52 62 83 100
Intermittent (3 x 551-690 V) [A] 45.1 57.2 68.2 91.3 110
Continuous kVA (550 V AC) [kVA] 41 51.4 61.9 82.9 100
Continuous kVA (575 V AC) [kVA] 40.8 51.8 61.7 82.7 99.6
Continuous kVA (690 V AC) [kVA] 49 62.1 74.1 99.2 119.5
Max. input current
Continuous (3 x 525-690 V) [A] 49 59 71 87 99
Intermittent (3 x 525-690 V) [A] 53.9 64.9 78.1 95.7 108.9
Max. pre-fuses
1)
[A]
100 125 160 160 160
Additional
specifications
Estimated power loss at rated max. load [W]
4)
592 720 880 1200 1440
Max. cable size (mains, motor, brake) [mm
2
]/(AWG)
2)
[95]/(4/0)
Weight
IP21
[kg] 65
65
65 65 65
Weight IP55 [kg]
65 65 65 65 65
Efficiency
4)
0.98 0.98 0.98 0.98 0.98
Table 10.11 Mains Supply 3 x 525-690 V AC IP21-IP55/NEMA 1-NEMA 12
1)
For type of
fuse see 10.3 Fuse Tables
2)
American Wire Gauge
3)
Measured using 5 m screened motor cables at rated load and rated
frequency
4)
The typical power loss is at normal load conditions and expected
to be within
±
15% (tolerance relates to variety in voltage and cable
conditions).
Values are based on a typical motor efficiency (eff2/eff3 border line).
Lower efficiency motors will also add to the power loss in the
frequency converter and vice versa.
If the switching frequency is raised from nominal the power losses
may rise significantly.
LCP and typical control card power consumptions are included.
Further options and customer load may add up to 30 W to the
losses. (Though typically only 4 W extra for a fully loaded control
card or options for slot A or slot B, each).
Although measurements are made with state of the art equipment,
some measurement inaccuracy must be allowed for (
±
5%).
