Figure 24: Cold room conguration with door and light
heat control function
AK-CC55 connections and application options
Upper and lower connection labels are laid out as shown in gure:
Figure 25: Electrical connections AK-CC55 Single Coil
40
41
42
5V
s
AI1
43
44
AI2
45
46
AI3
47
48
AI4
49
50
AI5
51
52
AI6
53
54
DI1/
AI7*
60
61
DI2
70
71
AO1*
PWM
83
84
85
B
A
MODBUS
115 - 230V AC
L
N
1
2
3
8
9
7
10
11
12
DO2
13
14
DO3
15
16
17
DO4
18
19
20
DO5
21
22
DO6
115-230V AC
30
31
DI3
Danfoss
84B3234
AK-CC55 Single Coil is optimised for control of one expansion valve + dierent combinations of light, rail heat and
alarm relays. It has 6 Digital Outputs (DO), known as DO1 – DO6, one Analogue Output (AO), known as AO1, 6
Analogue Inputs (AI), known as AI1 – AI6, an input that can be used as either DI1 (Digital Input) or AI7 (Sensor Input),
and 2 Digital Inputs, known as DI2 - DI3. AI7 (DI1) can be congured as S5B defrost sensor in application 1-6 and
application 9.
DO1 will be congured for a liquid line solenoid valve if the analogue output AO1 is congured for control of a
stepper valve driver.
Table 8: The controller covers the following nine applications:
Application 1-3
Plugin cabinets. Cabinets with dierent output combinations of alarm, rail heat and light.
Application 4
Remote cabinet including alarm, rail heat, defrost, light and fan.
Application 5
Remote hot gas defrost with suction, drain and hot gas valve.
Application 6
Back-to-back cabinet with one evaporator.
Application 7
Back-to-back cabinet with two evaporators.
Application 8
Cold storage room with defrost and simple humidity control.
Application 9
Custom
dened application, where the outputs can be congured according to custom requirements
Table 9: Application with digital and analogue output specication
No.
Application description
DO1
DO2
DO3
DO4
DO5
DO6
AO1
1
Plug-in cabinet
2
Plug-in cabinet
3
Plug-in cabinet
4
Remote cabinet
5
Remote Hot gas defrost
(Suction)
(Drain)
(Hot gas)
6
Back-to-back cabinet
7
Back-to-back cabinet
B
A
8
Cold storage room
humidity
9
User def. cong.
User def.
User def.
User def.
User def.
User def.
AK-CC55 Single Coil and Single Coil UI
© Danfoss | Climate Solutions | 2021.02 BC364229688105en-000101 | 24
