Page #59 background imageLoading...
Page #59 background image
6.4.9 Control Card, RS-485 Serial Communication
Terminal number 68 (P, TX+, RX+), 69 (N, TX-, RX-)
Terminal number 61 common for terminals 68 and 69
6.4.10 Control Card, 24 V DC Output
Terminal number 12
Maximum load 80 mA
6.4.11 Relay Output
Programmable relay output 2
Relay 01 and 02 01-03 (NC), 01-02 (NO), 04-06 (NC), 04-05 (NO)
Maximum terminal load (AC-1)
1)
on 01-02/04-05 (NO) (Resistive load) 250 V AC, 3 A
Maximum terminal load (AC-15)
1)
on 01-02/04-05 (NO) (Inductive load @ cosφ 0.4) 250 V AC, 0.2 A
Maximum terminal load (DC-1)
1)
on 01-02/04-05 (NO) (Resistive load) 30 V DC, 2 A
Maximum terminal load (DC-13)
1)
on 01-02/04-05 (NO) (Inductive load) 24 V DC, 0.1 A
Maximum terminal load (AC-1)
1)
on 01-03/04-06 (NC) (Resistive load) 250 V AC, 3 A
Maximum terminal load (AC-15)
1)
on 01-03/04-06 (NC) (Inductive load @ cosφ 0.4) 250 V AC, 0.2 A
Maximum terminal load (DC-1)
1)
on
01-03/04-06 (NC) (Resistive load)
30 V DC, 2 A
Minimum terminal load on 01-03 (NC), 01-02 (NO) 24 V DC 10 mA, 24 V AC
20 mA
Environment according to EN 60664-1 Overvoltage category III/pollution degree 2
1) IEC 60947 parts 4 and 5.
6.4.12
Control Card, 10 V DC Output
1)
Terminal number 50
Output voltage 10.5 V ±0.5 V
Maximum load 25 mA
1) All inputs, outputs, circuits, DC supplies and relay contacts are galvanically isolated from the supply voltage (PELV) and other
high-voltage terminals.
6.4.13 Ambient Conditions
Enclosure IP20, IP54
Enclosure kit available. IP21, TYPE 1
Vibration test 1.0 g
Maximum relative humidity 5%–95% (IEC 60721-3-3; Class 3K3 (non-condensing) during operation
Aggressive environment (IEC 60721-3-3), coated (standard) frame H1–H5 Class 3C3
Aggressive environment (IEC 60721-3-3), non-coated frame H6–H10 Class 3C2
Aggressive environment (IEC 60721-3-3), coated (optional) frame H6–H10 Class 3C3
Aggressive environment (IEC 60721-3-3), non-coated frame I2–I8 Class 3C2
Test method according to IEC 60068-2-43 H2S (10 days)
Ambient temperature
1)
See maximum output current at 40/50 °C (104/122 °F) in chapter 6.1.2 3x380–480 V AC
Minimum ambient temperature during full-scale operation 0 °C (32 °F)
Minimum ambient temperature at reduced performance -20 °C (-4 °F)
Minimum ambient temperature at reduced performance -10 °C (14 °F)
Specifications Quick Guide
MG18A622 Danfoss A/S © 08/2014 All rights reserved. 57
6 6
