1.2. Selecting the device
The selection of the correct device version is linked to the detection area needed, which is considered
as the sensitive area height of the device as well as to the maximum operating distance, considered
as the distance between the emitter unit (TX) and receiver unit (RX) and optics interaxis.
Versions are available:
Operating distance
Detection field
interaxis
DS2-05-07-015-JV
5m
21 beams; h=150mm
6.75mm
DS2-05-07-030-JV
5m
42 beams; h=300mm
6.75mm
DS2-05-07-045-JV
5m
63 beams; h=450mm
6.75mm
DS2-05-07-060-JV
5m
84 beams; h=600mm
6.75mm
DS2-05-07-075-JV
5m
105 beams; h=750mm
6.75mm
DS2-05-07-090-JV
5m
126 beams; h=900mm
6.75mm
DS2-05-07-105-JV
5m
147 beams; h=1050mm
6.75mm
DS2-05-07-120-JV
5m
168 beams; h=1200mm
6.75mm
DS2-05-07-135-JV
5m
189 beams; h=1350mm
6.75mm
DS2-05-07-150-JV
5m
210 beams; h=1500mm
6.75mm
DS2-05-07-165-JV
5m
231 beams; h=1650mm
6.75mm
DS2-05-25-045-JV
10m
18 beams; h=450mm
25mm
DS2-05-25-060-JV
10m
24 beams; h=600mm
25mm
DS2-05-25-075-JV
10m
30 beams; h=750mm
25mm
DS2-05-25-090-JV
10m
36 beams; h=900mm
25mm
The functions characterising the DS2 AREAscan
TM
light grids are available on all the versions that
consequently have the same operating modes.
The specific technical characteristics (e.g. resolution, sensitivity etc) remain the same for all the
versions, until differently indicated.
For food industry applications, please verify with DATALOGIC Technical Support the compatibility of
the materials of the light grid shell with the eventual chemical agents that are used in the production
process.
